SCHNEIDER EASYPACT CVS160F MCCB BREAKER, 36 KA AT 415 VAC, 3P 3D, MA 150A

EasyPact CVS160F circuit breaker, 36 kA at 415 VAC, 3P 3d, MA 150 A trip unit.

Label : EasyPact CVS

Range : EasyPact

Earth

Leakage protection : without

[In] rated current :

Breaking capacity code : F

Network type : AC

Range of product : Easypact CVS100...250-[Ue] rated operational voltage :

Breaking capacity :

Utilisation category : category A

Product name : EasyPact CVS

Suitability for isolation :

Product or component type : circuit breaker

Trip unit name : MA

Trip unit technology : magnetic

Trip unit rating :

Protection type : short-circuit protection (magnetic)

Device short name : CVS160F

Device application : motor-poles description : 3P

Protected poles description : 3d

Range Presentation : EasyPact CVS range is the easy choice for quality and value. Designed to meet the requirements of the majority of common protection applications in small to medium-sized buildings, EasyPact CVS circuit breakers deliver a high level of performance and cost-saving functionality that is unusual in their price range.

Rated current from 16 to 630 A

Breaking capacity from 25 to 50 kA at 400/415 V

3 and 4 pole versions

3 frame sizes

Thermal

Magnetic and electronic protection available for the entire range

Extended, adjustable thermal protection from 0.7 to 1 times (TMD) or 0.5 to 1 times (electronic) the rating of the trip unit

Common accessories and auxiliaries with other Schneider Electric MCCB offers

Suitable for isolation

Earth

Leakage protection by associated Vigi Module

Switch

Disconnector versions also available

Compliance with international standards : IEC 60947-2, CCC, EAC and other local certifications

Green Premium product

Range Benefits :

Specifiers – Conforms to international standards : IEC60947-2, and meets the requirements of the majority of common protection applications

Panel builders – Ease of installation. Only three frame sizes up to 630 A. Common accessories for complete range. Economic and competitive solution, yet meets major requirements of specifiers and clients

OEMs – High endurance and maintenance free operation ensures continuous performance of machines

Clients – Well balance of budget and quality, performance, reliability

Range Application Presentation : Protection and management of low-voltage electrical installations :

Standard applications : industries, buildings

Earth

Leakage protection

Motor protection

Generator protection

Switch

Disconnectors
