FLUKE INDUSTRIAL TRUE RMS MULTIMETER 87V

  • bvseo_sdk, net_sdk, 2.2.0.2
  • getAggregateRating, method:CLOUD, 515ms
  • REVIEWS, PRODUCT
  • bvseo-msg: Execution timed out, exceeded 500ms;
FLUKE INSTRUMENTS FLUKE
UOM: PC
Price w/GST:
$720.00


Unique function for accurate voltage and frequency measurements on adjustable speed motor drives and other electrically noisy equipment
Built-in thermometer conveniently allows you to take temperature readings without having to carry a separate instrument
Optional magnetic hanger for easy set-up and viewing while freeing your hands for other tasks
Large digit display with bright, two-level backlight makes the 87V significantly easier to read than older models
True RMS AC voltage and current for accurate measurements on non linear signals
Selectable filter for accurate voltage and frequency measurements on motor drives
0.05 % dc accuracy
6000 counts, 3-3/4 digits
4-1/2 digit mode for precise measurements (20,000 counts)
Measure up to 1000 V AC and DC
Measure up to 10 A, 20 A for up to 30 seconds
Built in thermometer lets you carry one less tool (TC probe included)
Frequency to 200 kHz and % duty cycle
Resistance, continuity and diode test
10,000 µF capacitance range for components and motor caps
Min/Max-Average recording with Min/Max Alert to capture variations automatically
Peak capture to record transients as fast as 250 µs
Relative mode to remove test lead interference from low ohms measurements
Auto and manual ranging for maximum flexibility
Touch Hold to capture stable readings avoiding noisy signals
Large display digits and two-level bright white backlight for increased visibility
Analog bargraph for fast changing or unstable signals
Input Alert provides audible warning against wrong use of input jacks
Improved selectable sleep mode for long battery life
Access door for fast battery changes without breaking the calibration seal
Classic design with new removable holster with built in test lead and probe storage
Voltage DC Maximum Voltage 1000V
  Accuracy ±(0.05%+1)
  Maximum Resolution 10 µV
Voltage AC Maximum Voltage 1000V
  Accuracy ±(0.7%+2) True RMS
  AC Bandwidth 20kHz with low pass filter; 3db @ 1kHz
  Maximum Resolution 0.1 mV
Current DC Maximum Amps 10A (20 A for 30 seconds maximum)
  Amps Accuracy ±(0.2%+2)
  Maximum Resolution 0.01 µA
Current AC Maximum Amps 10A (20 A for 30 seconds maximum)
  Amps Accuracy ±(1.0%+2) True RMS
  Maximum Resolution 0.1 µA
Resistance Maximum Resistance 50 MO
  Accuracy ±(0.2%+1)
  Maximum Resolution 0.1O
Capacitance Maximum Capacitance 9,999 µF
  Accuracy ±(1%+2)
  Maximum Resolution 0.01 nF
Frequency Maximum Frequency 200 kHz
  Accuracy ±(0.005%+1)
  Maximum Resolution 0.01 Hz
Duty Cycle Maximum Duty Cycle 99.90%
  Accuracy ±(0.2% per khz +0.1%)
  Maximum Resolution 0.10%
Temperature Measurement -200.0°C - 1090°C
  -328.0°F - 1994.0°F
  excluding probe
80 BK Temperature Probe -40.0°F - 500°F, 2.2°C or 2% whichever is greater

Conductance Maximum Conductance 60.00 nS
  Accuracy ±(1.0%+10)
  Maximum Resolution 0.01 nS
Diode Range 3 V
  Resolution 1 mV
  Accuracy ± (2 % + 1)
Duty Cycle Range Accuracy Within ± (0.2% per kHz + 0.1 %)
