SCHNEIDER MINIATURE CIRCUIT BREAKER (MCB), IC60N, 2P, C, 1A

iC60N

Miniature circuit breaker

2P

1A

C curve.

Label : Acti 9 iC60

Device application : distribution

[In] rated current : 1 A

Network type : AC,DC

Trip unit technology : thermal

Magnetic

Curve code : C

Breaking capacity code : N

Range : Acti 9

Breaking capacity : N/A, N/A, N/A, N/A, N/A, N/A, N/A

Utilisation category : category A conforming to EN 60947-2, category A conforming to IEC 60947-2

Suitability for isolation : yes conforming to EN 60898-1, yes conforming to EN 60947-2, yes conforming to IEC 60898-1, yes conforming to IEC 60947-2

Range of product : iC60

Standards : IEC 60947-2,EN 60898-1,EN 60947-2,IEC 60898-1

Quality labels : NF

Product name : Acti 9 iC60

Product or component type : miniature circuit-breaker

Device short name : iC60N

Poles description : 2P

Number of protected poles : 2

Range Presentation : With exclusive features, the Acti 9 iC60 DIN rail MCB is definitely geared to absolute safety and improved continuity of service.

VisiSafe : for safe operation and maintenance work on circuits.

Class-2 insulation : continuous safety for operators and unqualified personnel.

VisiTrip : detects faulty Miniature Circuit

Breaker outgoers quickly and reduces intervention time.

Add-on fully immune earth leakage protection devices : better continuity of service, especially in polluted environments and networks.

Nominal current : 1 to 63 A

Large choice of breaking capacities up to 100 kA and tripping curves : B, C, D, Compliance with standards IEC/EN 60898 or IEC/EN 60947-2,

Full coordination with Acti 9 range Residual Current Devices (RCDs) and Compact NSX Moulded Case Circuit Breakers (MCCBs),

Suitable for isolation in accordance with industrial standard IEC 60947

Operating voltage : up to 440 V AC, insulation voltage : 500 V

Optional add-on earth leakage modules : iC60 Vigi,

Optional auxiliaries : indication of state and tripping, shunt tripping, undervoltage tripping, overvoltage tripping,

Range Benefits :

The new reference in final distribution,

Absolute safety of circuit protection with VisiSafe,

Greater continuity of service with VisiTrip,

Simple to choose with meaningful part numbers,

Easy to install with quick, ergonomic & safe IP20B terminal shutters & robust connections (twice the standard tightening torque),

Environmentally friendly with 100% recyclable & recoverable materials.

Range Application Presentation : Low-voltage final distribution

Protection of electrical circuits in all industrial and commercial buildings,

All applications, especially in polluted environments and networks,

Motor circuit protection,

DC current circuit protection.
